ENGINEERING SERVICES WE PROVIDE

  • CONCEPTING & PROCESSING
  • We can analyze different processing ideas from the start of your project and help you decide the best approach to consider. With our experience, we will look for the most economical and practical way to achieve your goals. After review of your information and specs we can provide a Quote for this service if C&P is what you require.
  • SKETCHING
  • After a Concept is established by the customer or us, we can provide sketches drawn in 2D AutoCad or hand drawings to show the main components complete with callouts and notes for the purpose of understanding how the proposed design looks and functions.
  • DESIGN, DETAILING & CHECKING
  • We will provide a full set of assembly and detail drawings then after your approval, we will check all drawings and make any/all changes before shipping the final drawings to you. NOTE: We are able to provide either 2D or 3D formats for our customers. If you request a quote, (RFQ) please state the format that you require or desire. Many of our customers prefer 2D since it is faster for us to complete a project due to our vast experience in 2D. This quicker turn around has proven to be more cost effective for our customers. We also understand that some customers require 3D to integrate our designs with their systems etc.  At your request, we can quote both formats, for you to compare.
  • Lastly, our drawings of automated machines will include all required sensors and a charted Sequence of Operation including sensor numbers, but will not include a Controls Program.



INTERNATIONAL MANUFACTURING TECHNOLOGY SHOW WEBSITE THEME Vi

This Video follows the main theme of the International Manufacturing Technology Show (IMTS) which is   "be productive"

The VIDEO closes with shots of a Robot Cell that was designed by PROductive Engineering.

Also See VIDEO #2  featuring just the Robot Cell  IN ACTION

IMTS SHOW robot cell VIDEO #2

This video features the Robot Cell  IN ACTION  to demonstrate it's functions as it picks up one of the blanks from a loading tray and loads it into a Brother CNC machine.

Notice that we equipped the wrist with two back-to-back grippers so that just before the robot loads the blank, it picks up the completed part with the empty gripper and then the wrist rotates 180 degrees to then load the new blank.

Next the robot returns the completed part and places it back into the tray.

RAPID Pick & Place Video VIDEO #3

Check out this Awesome real time video of a complete pick & place system designed by,

          PROductive Engineering

          This "Rapid loader" loads a "Projection Nut" into a proposed "Die Welder" at the fast rate of one part per second.

Customers design criteria :

  • 3" height die opening,
  • 6" minimum reach
  • 1 sec. total cycle time
  • Example shown here, 18 parts in 18 seconds being loaded onto a simulated Fixture Pin made to accomodate 18 parts.

VIDEO #4 TWO PARTS AT A TIME WELDER (RIGHT SIDE ONLY)

Check out this cool video Designed for Tipaloy Inc.    A Double Fixtured Machine that after manually loading the stampings, Auto loads two projection nuts with two Lizard Tongues and after welding, simultaneously auto unloads both completed assemblies, to in effect double the production rate.
